Continue Power: 1600 W
Max. Output Surge: 3200 W
DC Input Voltage: 12V or 24V or 48V
AC Input Voltage: 100V/110V/115V/120V or 200V/220V/230V/240V
Diamensions (mm): 327 x 230 x 73
Weight (kg): 3.84 kg
‧Output type:
Wired Remote Control
Wireless
‧Features :
High technology of CPU modularity designed for wide-range appliances, pure sine waveoutput with THD <2.0%
Suitablefor different kinds of loads, resistive, capacitive etc.
High Surge capacity for starting demanding loads.
Perfect LED to show the working status
External connection with battery designed for easy replacement and usage time.
Wired remote control or wireless remote control (optional)
Full protection : output shortage, outputoverload, high voltage alarm & protection, low voltage alarm & protection.
Light, stylish and modern aluminum casing designed for easy carrying.
Intelligent temperature fans, automotive switch.
‧Scope of Application :
Medical Instruments, Emergency Power, Oxygen Concentrators, Cash Register, Home Theater, High-end Stereos,Computers, Power Tools, Radios, DVD players, TV’s , Musical Instruments, Recording Equipments, Limousines, Buses, RV’s, Precision Equipment, SensitiveRadio Equipment, Laser Printers, Fax Machines, etc.
‧Specifications:
Model
SU-12160/E
SU-24160/E
SU-48160/E
Output
Continuous output
1600W
Surge Power
3200W
AC Voltage
AC 100V / 110V / 115V / 120V or 200V/ 220V / 230V / 240V to be selected
Regulation
Vrms ± 3%
Frequency
50Hz or 60Hz ± 1
Wave Form
Pure Sine Wave
Total Harmonic Distortion
THD ＜ 3%
USB Output
DC 5V ± 5% 500mA
Input
Battery Voltage
DC 12V
DC 24V
DC 48V
DC Current (typ.)
160A
80A
40A
Low Battery Alarm
DC 12V/10.5V ± 2%
24V/21V ± 2%
48V/42V ± 2%
Low Battery Protection
DC 12V Selected:10V,11V, 11.5V ± 2%
DC24V Selected: 20V,22V, 23V ± 2%
DC48V Selected: 40V,44V, 46V ± 2%
High Battery Protection
12V/15.5V ± 2%
24V/31V ± 2%
48V/62V ± 2%
No load current
12V/0.82A
24V/0.5A
48V/0.3A
Efficiency
＞ 90% (at full load)
Protection
High temperature
Yes
Short-circuit
Yes
Overload
Yes
Input Voltage
Yes
Operating temperature range
-20℃~ 50℃
Operating Humidity
0~90 %
Intelligent Design Heat Auto Control
Fan Start speeding up : 38℃ ± 3 , Fan Stopspeeding up : 42℃± 3
High Temperature Shut Down : 63℃±5 , Restart Output : 56℃±3
