Input capacity: up to 25 tubes (SOIC)

Package types: SO, SOJ

LCD monitoring (human-machine interface for the setting of modes and values)

Adjustable speeds (UPH): 5-7.2K/hr

Width of packing tapes: 8mm-56mm (black or transparent tape)

Rail width and depth adjustable

Sealing modes: reciprocative sealing (sealing height/length/travel adjustable), continuous sealing, cold sealing, or hot sealing

Two independent thermostatic sealing shoes and two temperature controllers

Counting methods: front blank-tape counting, load counting, rear blank-tape counting, non-sealing counting

Optional: viewing system

Image treatment device is optional (can be installed per customer request)

Pneumatic source: 70 psi

Power: 220V; 50/60Hz; single phase 1o

Net weight: approximately 300kg

Gross weight: approximately 380kg

Packing measurements: W 1,400 x L 1,700 x H 1,850 (mm)

The appearance or functions of our machines are subject to change without prior notice!
