Specification
*Compressor: 3/4HP
* Vacuum pump: 3.2CFM (1/3HP)
* Measurement: H112xW61xD51cm
* Weight: 83.5kgs
* Liquid storage: 12kgs
* Voltage: 110V 60Hz
* Appliance Freon: R-12 R-134a
* Appliance site: car maintenance, small size air conditioner repair
Function
* Recycle, fill, reclaim, wash, vacuum, survey divulges 6 in 1.
* By hand/automatic air and exhaust equipment.
* Air and liquid Freon are recyclable. Recycle speed: liquid about 0.76Kg/min Air about 0.45kg/min
* Froen basket is attached with measurement and liquid level ball. The stock of recycle, capacity and fill can be seen clearly.
* During recycle process that impurity, vapour, oil air, acid material can be separated and exhausted. It can exhaust air automatically.
* Once the recycle process is finished, machine will stop, unload, automatically.
* Assembled with Freon recycle window enable to inspect the procession.
* Stores the fluid loaded in barrels to have the liquid level indicator, in has the fluid position ball, but clearly sees the cold intermediary storage quantity, the recycling quantity and fills the quantity.
* The equipment high-quality ball valve switch, firm is durable, airtight.
* Stores the fluid barrel, the oil separator, the heat interchanger completely all is the galvanized iron material quality, never Rusty, strengthens the reclaimer life.
* Installs three minutes engines off protective device, avoids reclaimer engine off immediately opening machine.
|
|
