床型立式銑床

床型立式銑床

Hot
產品型號:
DM-520V
顏色:
接受訂製

詳細規格及用途描述

Model: DM-520V
SPINDLE TAPER---NT#50
SPINDLE SPEEDS---45~1500RPM(Variable/18 STEPS CHANGE)
SPINDLE MOTOR---10HP x 4P AC
TABLE SIZE---17.7” x 59”(450 x 1500mm)
X/Y/Z AXIS TRAVEL---1100/500/500mm
MAX. LOADING WEIGHT---1000kg
AUTO LUBRICATION SYSTEM
SPINDLE LUBRICATION SYSTEM
ELECTRIC CONTROL BOX
BALL SCREWS ON X, Y, Z AXIS
PRACTICAL TELESCOPIC COVER
AIR DRAW BAR
HALOGEN WORK LIGHT
HORIZONTAL MILLING HEAD
TOOLS & TOOL BOX
OPERATION MANUAL
NET WEIGHT: 3800kg

公司名稱: 隆翰興業有限公司
地址: (office) 5F NO. 146-29 SEC. 1 DONGSHAN RD. TAICHUNG CITY 40647 TAIWAN
電話: 886-4-2437-5196
傳真: 886-4-2437-5149
E-Mail:
網址: www.dynawaytech.com

發送詢問函給廠商
