HYDRAULIC CRANKSHAFT GRINDER SCHOU1500
HYDRAULIC CRANKSHAFT GRINDER SCHOU1500

Model:SCHOU 1500 Country of Origin:Denmark

Detail Specifications / Descriptions

Capacity
Max. distance between
centres 1500mm
Max. distance between
chucks 1470mm
Swing over table 520mm
Stroke 200mm
Max. weight of crankshaft,
approx 600kg

Operating speeds
Workhead 20-25-40-50-75-100 r.p.m
Table traverse, manual 6 mm per rev.
Table traverse, power 3500 mm/min.
Wheelhead feed, hydraulic 2000 mm/min
Wheelhead feed, graduation 0.005 mm

Grinding wheel
Diameter 700 mm
Widths minimum - maximum 19-45 mm

Electric motors
Wheelhead motor, totally enclosed 900 r.p.m.
Workhead motor, 2-speeds 900/700 r.p.m
Motor for table power traverse 900 r.p.m.
Motor for hydraulic traverse of wheelslide 1400 r.p.m
Coolant pump motor 2800 r.p.m.

Dimensions
Overall length 3620 r.p.m.
Overall width 1600 r.p.m.
Height, floor to spindle centres 1100 r.p.m.
Work space required 1800*5400 mm
Net weight, approx. 3950 kg
Gross weight, approx. 4500 kg
Box size 3395*1790*1550 mm
