Type: Bed Type Deep Hole Drilling Machine
• The Column type Deep hole drilling machine with CNC control are designed for drilling waterlines, Ejector pin holes of large type injection molds.
• Spindle is supported by angular contact bearings well-lubricated to all running points in the head.
• The rigid honeycomb walled column gives a stable cutting condition. FC-32 castings have been stress relived and annealed.
• Hardened and ground double V-ways for worktable X-axis main slide to hardness HRC 60. The opposite ways and gibs are all Turcite-B plated with hand scraped bearing surface.
• A huge wide and long worktable allows heavy work pieces. And extra wide saddle gives much heavier loading capacity.
• Automatic lubrication pump is provided as standard accessory to ensure all the bearing surface and screws are well lubricated.
• Spindle feed Z-axis and A-axis, feature P-grade linear motion guide way and provides stable cutting capacity.
• CNC could be selected with Fanuc or Mitsubishi brands.
• CE mark are available for special required.
