PXIe Backplane

PXIe Backplane

  • 產地(所在國):台灣
  • 型號:PXIe Backplane

詳細規格及用途描述

Features:
1. 10-slot PXI Express backplane with one system slot, one system timing slot, seven hybrid slots
2. 82W per slot of power and cooling
3. Custom chassis and configurations are available.

Specifications:
Part No. BP-310-PXIe-7010
3U 10-slot PXIe backplane
Total Slots 10 slots
System Controller Slot 1 slot
Hybrid Slot 7 slots
System Timing Slot 1 slot
System Bandwidth 16 GB/s
Cooling Capability 82W
Max Total Usable Power 950W
+3.3V Max Load 34A
+5V Max Load 34A
+12V Max Load 75A
-12V Max Load 1.75A
Fans Two 186 CFM fans
Operating Temperature 0°C to 55°C
