Contact resistance: 50 Mohm max. per pole

Current rating: 3-pole15A, 5&6-pole7. 5A, 7-pole5A at 125VAC

Insulation resistance: 1000 Mohm min.

Electronic withstanding voltage: 1000 V(RMS)

Insertion forces: 7 lb. max. , 5 lb. nominal

Withdrawal forces: 7 lb. max. , 5 lb. nominal

Insert insulation: high-impact, molded thermoplastic

Insert screw: stainless steel

Insert insulation: high strength, reinforced thermoset plastic

Pin contact: 3-5 (min. ) microinch gold (over 3-5 microinch nickel) plated

Primary Competitive Advantages:

International Approvals

Experienced Technical Staff

Brand-name Parts

Product Performance

Delivery Details:

Lead Time: 2-3 weeks
