Short-Circuit Protected Power Inverter with Soft Start Design
Model:
GP-12/24/48-150
> Detail Specifications / Descriptions
Key Specifications/Special Features:
Continuous power output: 150W
Output power surge: 450W
DC input voltage:
GP-12-150: DC 10V to 15V
GP-24-150: DC 20V to 30V
GP-48-150: DC 40V to 60V
Low battery alarm:
GP-12-150: DC 10. 5V +/- 0. 5V
GP-24-150: DC 21V +/- 1V
GP-48-150: DC 42V +/- 2V
Low battery shuts down at:
GP-12-150: DC 10V +/- 0. 5V
GP-24-150: DC 20V +/- 1V
GP-48-150: DC 40V +/- 2V
High battery shuts down at:
GP-12-150: DC 15. 5V +/- 0. 5V
GP-24-150: DC 30V +/- 1V
GP-48-150: DC 60V +/- 2V
Short-circuit protection: yes
No load current draw: < 0. 3A
Alarm and thermal shut down: 60 +/- 5 degrees Celsius
DC input fuse:
GP-12-150: 20A
GP-24-150: 10A
GP-48-150: 5A
Net weight: 0. 85kg
100% lead-free aluminum casings
Output receptacles 7 types of sockets: Japan, US, Australia, UK, France, Europe, Universal
Main Export Markets:
Worldwide
