A512506 Hydraulic Valve Lifter Puller
Hot- Model:
- A512506
Detail Specifications / Descriptions
.These specialised tools are designed to both remove the diesel pump (detaching the pump from the pump sprocket) and to retain the position of the pump sprocket in-situ, whilst the pump is removed and off the engine. This allows the front .sprockets/timing chain configuration to remain undisturbed and under reducing the level of engine dis-assembly required
A: Pump Remover & Sprocket Retaining Tool covers injection/HP pump removal on BMW models with M47/M47TU and M57/ M57TU 2.0 & 3.0 diesel engines
B: Pump Remover & Sprocket Retaining Tool covers injection/HP pump removal on LAND ROVER FREELANDER and ROVER 75 models with Td4 and M47 2.0 diesel engines
.A and B are similar, with the B being shorter in order to accommodate restricted access on the engines fitted transversely
.The application procedure for fitting and using these tools is identical
.The main purpose of these tools is extract the pump from the sprocket and retain the position of its in-situ, whilst the pump is removed and off the engine This allows the front sprockets/timing chain configuration to remain undisturbed and under tension, thus reducing the level of engine disassembly required
