CNC LATHE

CNC LATHE

Model:
MT-210

Detail Specifications / Descriptions

MODEL MT-210
Machine type Linear (Box)
Machine body type Slant
Swing over bed 545 mm
Standard turning dia 350 mm
Max. turning dia 350 mm
Max. turning length 500 / 750 mm
Bar capacity 75 mm
X-axis stroke 380 mm
Z-axis stroke 530 / 780 mm
Spindle speed 4000 rpm
Spindle nose A2-8
Spindle thru-hole dia 91 mm
Spindle bearing inside dia 130 mm
Type of turret 12
Height of square tool 25 mm
Dia of boring bar holder 40 mm
3-jaw Chuck 10"
Stroke of tailstock 350 / 500 mm
Tail sleeve dia 85 mm
Taper of tailstock MT #5
Tail sleeve stroke 100 mm
Rapid feed speed X:20 / Z:24 m/min
(opt.:30 for Linear)
Spindle motor 11 / 15 kW
Lubricating oil motor 1.5 kW
Cutting oil motor 0.55 kW
Servo turret motor 1.2 kW
Electric power 30 KVA
Hydraulic pressure 50 L
Lubricating oil 1.8 L
Cutting oil 160 L
Floor space (L x W) 2300 / 3100 x 1500 mm
Net weight 4500 / 5000 kg
Standard Accessories Optional Accessories
◆ 3-jaw hydraulic chuck ◆ Bar feeder
◆ Hydraulic system ◆ Parts catcher
◆ Hydraulic tailstock ◆ Tool setter
◆ Live center ◆ C-axis
◆ Coolant system ◆ VDI turret
◆ Morse taper sleeve ◆ VDI tool holders
◆ Auto lubrication system ◆ Auto door
◆ Working light ◆ Chip conveyor
◆ Heat exchanger for electrical cabinet ◆ Chip bucket
◆ Soft jaw ◆ Transformer
◆ Foot switch for chuck clamp ◆ CE mark
◆ MPG handwheel ◆ Safety torque limit clutch
◆ Operation & maintenance manuals ◆ Hoisting hook package
◆ Tools and box ◆ Levelling kit
◆ Leveling bolts and screws ◆ Bar feeder interface (LNS system)
◆ OD tool holder ◆ Additional tool holders and sleeves
◆ Facing tool holder ◆ SIEMENS controller
◆ Boring bar holder & sleeves
◆ Drill sleeves
◆ FANUC controller



* The above specifications subject to change without prior notice.
