BRASS WIRE CUT EDM

Model PW-400S
Maximum workpiece size 700*540*295 mm
Work table size 640*500 mm
Maximum workpiece weight 500 kgs
Drive & Servo 5 axes AC Servo
Simulations Axis X/Y/U/V (4 axes)
X/Y axis travel 400 / 300 mm
Z axis travel 300 mm
U/V axis Trave 100 / 100 mm
Wire diameter range Ø0.1~0.3 mm
Max. taper angle (°)
workpiece thickness(mm) +-22.5 (100mm)
Maximum axes load 10 kgs
Conductivity Automatic
Water tank capacity 570 L
Net weight 2100 kgs
Dimension (W*D*H) 3100*2200*2150 mm

* The above specifications subject to change without prior notice.

Standard Accessories
Automatic vertical alignment jig *1set
Power feed contact *2pcs
Filter *2pcs
Clamping tool *1set
Wire guide (Ø0.25mm) *1set
Brass wire (Ø0.25mm) *1set
Ion exchange resin (5L) *1pc
Tool box *1set
