立式综合加工机
Hot- 产品型号:
- VMC-2210
- 原产地:
- 台湾
详细规格及用途描述
MODEL: VMC-2210
TRAVEL
X-axis: 2200mm
Y-axis: 1000mm
Z-axis: 700mm
Spindle nose to table: 250~950mm
Spindle center to column: 1000mm
FEED RATE
X/Y/Z axis rapid traverse: 10000mm/min.
Cutting feedrate: 10000mm/min.
TABLE
Table size: 2360 × 970mm
Max table loading capacity: 3000kg
Size of T-slot: 22 x 5 x 150mm(22 x 7 x 125mm---Opt.)
SPINDLE
Spindle speed: 4000RPM/6000RPM(Opt.)
Spindle taper: BT-50(BT-40---Opt.)
Transmission: 2-speed gear drive(direct-drive/belt drive---Opt.)
MOTOR
Spindle motor: 18.5kw/25HP
X/Y/Z axis motor: 7kw/7kw/7kw
ATC
Tool magazine capacity: 24(32/40---Opt.)
Max. tool weight: 15kg
Max. tool size(dia. x length): ψ110mm × 300Lmm
Tool shank: BT50(BT40---Opt.)
GENERAL INFORMATION
Machine net weight: approx. 21000kg
Floor space required(L×W×H): 4080 × 5720 × 3412mm
Shipment advice: flat rack container
