Vertical Machining Centers

Vertical Machining Centers

产品型号:
VMC-1370H

详细规格及用途描述

Model VMC-1370H
Travel:
X axis travel 1300 mm
Y axis travel 700 mm
Z axis travel 700 mm
Spindle nose to table 150~850 mm
Spindle center to column front 760 mm
Work Table :
Work table size 1400*700 mm
Max. table loading 1200 kg
T-slot pitch / width / no 125 x 18 mm x 5T
Feedrate :
X / Y / Z rapid feedrate 20 / 20 / 15 m/min
Cutting speed 10 / 10 / 10 m/min
Headstock :
Spindle motor cont. / 30min 11/15 kw
Spindle taper BT40 / BT50
Spindle speed 10,000/6,000 rpm (opt: 1,2000/15,000)
ATC :
Tool no & type 24 / 30 Arm
Max. tool diameter x length Ø80 x 300 mm/
Ø100 x 300 mm
Max. tool weight 7 / 15 kg
General information:
Air pressure 6 kg / c㎡
Coolant tank capacity 450L
Machine weight 10400 kg
Gross weight 11000 kg
Floor space (L x W x H) 340*248*280cm
Packing size (L x W x H) 385*310*315cm
Positioning 0.005 mm/ 300 mm
Repeatability +/-0.003mm
STANDARD ACCESSORIES
Mitsubishi M70-2A controller
Coolant system
Auto lubrication system
Working & warning lamps
Spindle air blast (M code)
Toolbox and tools
Fully enclosed splash guard
RS-232 interface
Rigid tapping
Auto power off
Heat exchanger for electric box
M.P.G
leveling bolts and pads
Power transformer
Manuals, quality check report and warranty note

* The above specifications subject to change without prior notice.
