ELECTRIC DISCHARGE MACHINE
ELECTRIC DISCHARGE MACHINE

產品型號:EDM-542C

詳細規格及用途描述

Item Unit EDM-542C
Work Table Size mm 800 x 450
X/Y/Z Axis Travel mm 500 x 400 x 350
Electrode Plate to Work Table mm 250 / 600
Max. Electrode Weight kg 180
Max. Workpiece Weight kg 1350
Z Axis Motor Panasonic K AC Servo 1.0 K
Z Axis Rapid Feed Rate m/min 5
Z Axis Cutting Feed Rate m/min 5
Work Tank Size mm 1300 x 700 x 460
Oil Tank Capacity L 650
Weight of Machine Unit kg 1850
Outside Dimensions mm 1600 x 1600 x 2250
Standard Accessories Optional Accessories
Paper filters Automatic fire extinguisher
Clamping kits EROWA accessory
Electrode holder Dielectric cooler
Tool box C axis
Flushing nozzle Permanent magnetic table
Working lamp ATC (Auto Tool Changer)
Drill chuck Power regular

公司名稱: 迅捷整合科技有限公司
電話: 886-4-2493-7866,2493-1088
傳真: 886-4-2493-3055
