Specification
* Compressor: 5HP (rotary compressor)
* Measurement: H115xW53xD78cm
* Weight: 160Kgs
* Liquid storage: 12Kgs
* Voltage: 3Ø 220V 60Hz
* Appliance Freon: R-22 (special order are welcome)
* Appliance site: Freon reloading factory Bus maintenance and middle size air conditioner repair
Function
* Recycle, fill, reclaim, wash 4 in 1.
* By hand/automatic air and exhaust equipment.
* In and out entrance are assembled with 2—and 6—connector.
* Air and liquid Freon are recyclable. Recycle speed: liquid about 5Kg/min Air about 1.6kg/min
* Froen basket is attached with measurement and liquid level ball. The stock of recycle, capacity and fill can be seen clearly.
* During recycle process that impurity, vapour, oil air, acid material can be separated and exhausted. It can exhaust air automatically.
* Assembled with Freon recycle window enable to inspect the procession.
* Automatic cool equipment is assembled. It won’t damage the compressor even for long time operation.
* It is assembled with the function of close down when the basket is full, alarm, 3 minutes protection switch.
* Liquid loading to avoid uncondensed air to exhaust. It stabilizes reloading speed.
* Once the recycle process is finished, machine will stop, unload, automatically.
