AD-TM-5008-08-TP 8 SPINDLE COIL TAPING MACHINE
AD-TM-5008-08-TP 8 SPINDLE COIL TAPING MACHINE

Model:AD-TM-5008-08-TP

Detail Specifications / Descriptions

Technical Specifications:
Number of spindles: 8
X\Y\Z Axes Control system: AC Servo Motor
Data storage: 1GB CF Card
Tape I.D.:Min:76mm Max:80mm
Tape O.D.:Min:85mm Max.130mm
Spindle Pitch: 50mm
Max. Bobbin Diagonal: 40 mm (Bobbin width under 32mm)
Spindle Speed: 3000 RPM
Spindle Direction: CW/CCW
Spindle Stop Accuracy: +/-0.225 degrees
Tape Width:Min:4mm Max:25mm
Maximum Travel Distance X: 60 mm
Maximum Travel Distance Y: 65 mm
Maximum Travel Distance Z: 65 mm
Power source: 1¢ AC 220V, 50/60 HZ
Consumed power: 1.6KW
Air Pressure Supply Required: 5~6 kgs /c㎡( =0.5~0.6MPA )
Machine Dimension (Not Include screen ): 90(L)X 95(W)x 170 (H)cm
Machine weight: 460KGS Options:
1.Automatic Load & Unload(Bobbin width under 22mm)
