Universal Knee Type Mill
Universal Knee Type Mill

產品型號:E-2500UM 原產地:台灣

詳細規格及用途描述

Universal Knee Type Mill



TABLE

Table area :1500 x 350mm

Number of "T" shaped slots :5-16H7

Distance between "T" shaped slots :60mm

Rotary movement of table in both direction :45°

TRAVERSE

Automatic longitudinal :1150mm

Automatic cross :400mm

Automatic vertical :500mm

Available distance from spindle to overarm :155mm

SPINDLE

Housing of the taper spindle :ISO-40/50

Diameter of the main shaft nose :88.88-128.57mm

Milling arbor diameter :27mm

Number of speeds of the spindle (R.P.M.) :12(40-1800)50Hz

FEEDS

Longitudinal and cross feeds :10-1208

Vertical feed :5-604

RAPID TRAVERSE

Longitudinal and cross :1208mm/min(60Hz)

Vertical :604mm/min

PUISSANCE

V-Belts :4

Main motor HP :7.5

Feed motor HP :2

COOLING

Cooling-pump HP :1/8

MOTORIZED OVERARM

Housing of the taper spindle :ISO-40/50

Number of speeds :12

Speed range (R.P.M.) : (35-1600) 50HZ

Power HP :5.5

WEIGHT

Maximum weight on table :700kg

Net weight :3500kg

Gross weight with seapacking case :3800kg

Cubical measure of packing :2.3x1.6x2.2m

※※ For more details please visit our web site at ※※ https://www.taiwanmachine.com.tw
