JIN JYE MACHINERY CO., LTD.

Product Information - 45 TON 3.5 OZ

Click for a larger picture
45 TON 3.5 OZ

Product Description
Product Name:	45 TON 3.5 OZ
Model:	JT-45 SCD

> Detail Specifications / Descriptions

‧45 TON 3.5 OZ
‧Double Slide Plate With Specific
‧Pressure & Specific Current Digital Control
‧Two-Sliding-Table Specific Pressure & Flow Speed Digital Control
‧Vertical Plastic Bakelite Injection Molding Machines

This swivel plate can be applied for altering the mold or designing, helping enhance the production efficiency and safe to use.

It is firm and durable with a specially designed steel structure.

The liquid loop adopts specific pressure & specific current and multi-segmental control and computer liquid crystal display. It has such properties as high sensitivity, precision and accuracy. Different specifications are available for your option.

Model		Unit	JT-45SCD
Injection Unit	Screw Dianter	MM	28	32	34
	Injection Pressure	kg/cm²	1392	1065	944
	Theoretical Shot Vlume	cm³	70	92	117
	Max. Shot Weight (PS)	G / OZ	64 / 2.3	85 / 3	107 / 3.8
	Max. Shot Weight (PS)	cm³ / sec	37	49	62
	Injection Rate	MM	130
	Screw Speed Max.	RPM	0-150
	Nozzle Comtact Force	ZONE	3
	Number of Temperater Control	L	20
Clanping Unit	Clamping Foce	T	45
	Opening Force	T	5
	Platen Size	MM	580 x 430
	Distance Between Tie Bere	MM	420 x 250
	Min. Mold Heigh	MM	210 / 150
	Opening Stroke	MM	200
	Max. Open Dayinght	MM	410 / 350
	Ejector Power	T	1.3
	Ejector Stroke	T	75m/m
Hydraulic Electricity Unit	Max. Hydraulic Pressure	kg / cm²	140
	Pump Output	L / MIN	39
	Oil Presservoir Capacity	L	130
	Cooling Eaer Consumotion	L	600-800
	Pump Motor Power	HP	7.5
	Berrel Heating Power	KW	3.5
	Total Weight	KW	9
Other	Machine Weight	T	2.4
	Machine Dimensions (LxWxH)	M	1.7 x 1.03 x 3.0
	Shipping Weight	T	2.7
	Shipping Measurements (LxWxH)	M	1.92 x 1.36 x 2.3
