Modular Solutions for Efficient Manufacturing

HIWIN Cartesian Robot is an essential component in automated machineries and production lines, designed to streamline operations with precision and reliability. HIWIN’s Cartesian Robots are assembled using Single-Axis Robots that are tailored to meet specific customer requirements.

By utilizing HIWIN’s expertise and precise manufacturing technology, the company delivers customized integration plans, ensuring optimized performance for various applications.

HIWIN Single-Axis Robots are modular solutions built on years of innovation, featuring proprietary ballscrew and linear guideway developed and manufactured in-house. This integration of ballscrew and linear guideway into a single-axis robot module offers a modularized design that simplifies installation and system inspection, saving both time and cost for customers. When paired with HIWIN’s Servo Motor and E series drive, the robot provides high-speed, repeatable positioning control, creating a robust mechatronic solution that integrates seamlessly into any automation setup. This easy-to-install, compact, high-precision system is suitable for a wide range of requirements, providing a space-saving option that adapts flexibly to various specifications.

HIWIN offers a comprehensive selection of Single-axis robots and accessories, allowing customization to meet specific needs.

● Single-Axis Robot KK Series

HIWIN KK Series is driven by a ballscrew guided on an optimized U-rail to achieve higher accuracy and greater stiffness. The features are high accuracy, high stiffness, saving space, suited for heavy-duty and stable operations

● Single-Axis Robot KC B-TYPE Series

HIWIN KC B-TYPE Series. Easy to install the product without opening the stage cover. And higher performance:10~30% loading capacity increased. Perfect for electronics and clean environments

● Single-Axis Robot KA Series

HIWIN KA Series uses lightweight aluminium base. The features are Lightweight, Lower height. Max stroke 3,000 mm, max linear speed 1.25~1.8 m/s, ideal for various and customized applications

● Single-Axis Robot KH Series

HIWIN KH series single-axis robots feature a modular design that combines high-load linear guideways with timing belt drives. Available in various sizes and stroke lengths, they can be customized in millimeter units to meet specific needs. Flexible multi-axis configurations help users quickly implement automation and improve precision.

HIWIN Cartesian Robots support a wide range of applications, such as automatic soldering, screw feeding, adhesive lamination, CCD lens shifting, automated spray painting, cutting, semiconductor manufacturing, and more. Each single-axis robot includes essential components such as a motor, drive, and upper controller, with HIWIN offering a selection of top-quality servo motors and drives that can be tailored to specific project needs. This adaptability also makes Cartesian Robots ideal for replacing traditional hydraulic and pneumatic cylinders, which significantly reduces energy consumption and increases output.

With a focus on efficiency and sustainability, HIWIN’s modular Cartesian Robots offer quick assembly, simple operation, and economical advantages, making them indispensable for automated systems that require both performance and environmental responsibility.
